1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories

    Buy cheap 1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories from wholesalers

    Buy cheap 1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories from wholesalers
    • Buy cheap 1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories from wholesalers
    • Buy cheap 1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories from wholesalers
    • Buy cheap 1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories from wholesalers
    • Buy cheap 1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories from wholesalers

    1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories

    Ask Lasest Price
    Brand Name : transfer flat cart with turntable on rails
    Model Number : transfer flat cart with turntable on rails
    Certification : CE ISO SGS
    Price : USD 3000~7800 set
    Supply Ability : 100 sets month
    Delivery Time : 20 work days after received balance payment
    • Product Details
    • Company Profile

    1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories

    Heavy load Electric Handling Bogie Turntable on Rail for Factories


    Introduction


    Henan Perfect Handling Equipment Co., Ltd. is specializing in the design and manufacture of heavy material transport system to solve every material handling requirement. Our product includes Industrial Trailers, Transfer Cars, Electric Railway Transfer Trolley, Battery Operated Transport Trolley, Coil and pipes Carrier Equipment, Ladle Handling Equipment, Hydraulic Lift Table, Turntables and many other specialty items.Our line of Industrial Transfer Carts are designed and manufactured to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others. These material handling equipment are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

    Details


    1t Heavy Load Electric Handling Bogie Turntable On Rail For Factories


    Technical Parameter
    ModelBWP-5tBWP-20tBWP-30tBWP-40tBWP-50t
    Rated Load(t)520304050
    Max. Wheel Load (t)2.85.67.71012
    Ground RequirementCement floor or Steel plate ground
    Ground Clearance(mm)5050505050
    Table Size (mm)3000 X 20004500 X 22005000 X 22005500 X 23006000 X 2300
    Height (mm)450600650700700
    Wheel Base (mm)15001700170018001800
    Axles Distance (mm)25003900430048005200
    Turning Radius (mm)25013901430148015201
    Turning StructureMechanical
    Motor Power (KW)3.57101215
    Wheel Diameter (mm)300 (4)400 (4)400 (6)500 (6)500 (6)
    Wheel MaterialZG55+hydropurture
    Running Speed (m/min)0-150-12
    Brake PrincipleElectric magnetic brake
    Operation MethodRaido Remote Control
    Battery MaintainanceFree of maintainance
    Charger's InstallationInstalled on cartSplit-type
    Cart ColorCustomized
    Charger's FunctionAutomatically cut off the power when the battery is fully charged
    Radar Control3-0.3 m, Automatic stop for obstacles
    Warning EquipmentHorn and Flash Light
    Other FunctionsTurning light, night light and power display
    Handling Bogie

    PERFECT conceives and manufactures a wide range of railway guided transfer carts, battery powered trolleys, intelligent self-propelled trolleys, die carts, industrial flat trailers, tilters and lifting platforms that operate in many industrial fields: metallurgy, manufacture, oil and gas, die shops, shipyards, chemical plant, automotive, mining industry, aerospace, power generation, coal industry, paper mills, metalworking, warehouse and many others!
    Q&A

    Will A Transfer Cart Be A Good Solution?
    A good question to ask since there are many material handling solutions on the market! Which one is the right choice? For starters, transfer carts are moveable platforms used for the horizontal movement of materials, assemblies, and other items. Consideration must be given to the weight of the load and the travel requirements for the application.
    What Are The Advantages of Using a Transfer Cart?
    For smaller loads, manual carts can be dedicated to specific work place activities such as shuttling materials. This often makes the carts more available for use. Transfer carts are more accommodating for moving long loads through restrictive passage ways or doorways. For heavier loads transfer carts are an excellent affordable choice for their ability to handle heavy loads. Transfer carts are compact in design and work well in areas with limited floor area. Another advantage over lift trucks is how the cart deck can be customized to suit specific loads.
    What Product Handling Applications Use Transfer Carts?
    1. Coils (V-Groove deck)
    2. Tanks (size/stability for uniformly distributed loads)
    3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
    4. Sub-Assembly shuttle from one line to another line
    5. Maintenance cart for motors and pumps
    6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
    7. Material shuttle for steel tubing (flat decking with guard rails)
    8. Elevating platform for assembly process (integrated screw-jack table)
    9. Sand casting (flat decking)
