Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material

Ask Lasest Price
Brand Name :	electric rail transfer cart for steel mill
Model Number :	electric rail transfer cart for steel mill
Certification :	CE ISO SGS
Price :	USD 2000~7900 set
Supply Ability :	100 sets month
Delivery Time :	20 work days after received balance payment

Add to Cart

Product Details
Company Profile

Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material

Heavy load 50t Rail Transfer Trolley Battery Powered Steel Factory Scrap Material

Product Introduction

With the functions of steady traveling, poleless speed regulation, PERFECT transfer trolley is commonly applied to transfer steel ladle, scrap,aluminum ladle, lead ladle, steel slag etc. We use this kind of scrap transfer trolley to moving and transporting hot metal ladles or scrap bucket to the ingot casting machines or within the plant itself.
Generally the outer surface temperature of the scrap bucket is 200-300 degree, due to the high temperature the scrap transfer trolley should be designed with heat exposure proof device, especially to the battery, motor, reducer and electric appliance. It can avoid the transfer trolley from damaging and shortening using time. In order to avoid the scrap bucket transfer trolley broken during working, there equipped two sets driving system, if the main driving system is broken, the spare driving system can be start at the same time.

Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material

Detailed Image

Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material

parameter table

Model		BXC-2t	BXC-20t	BXC-50t	BXC-100t	BXC-150t
Rated Load(t)		2	20	50	100	150
Table Size (mm)	Length(L)	2000	4000	5500	6500	10000
	Width(W)	1500	2200	2500	2800	3000
	Height(H)	450	550	650	900	1200
Wheel Base(mm)		1200	2800	4200	4900	7000
Rail Inner Gauge(mm)		1200	1435	1435	200	2000
Wheel Diameter (mm)		270	350	500	600	600
Running Speed (m/min)		0-25	0-20	0-20	0-20	0-18
Motor Power(kw)		1	2.2	5	10	15
Battery Capacity		180	180	330	440	600
Battery Voltage		24	48	48	72	72
Running Time When Full Load		4.32	4	3.3	3.2	2.9
Running Distance for One Charge(km)		6.5	4.8	4	3.8	3.2
Recommended Rail Model		P15	P24	P43	QU100	QU100

Company and Customers' visit

Henan Perfect Handling Equipment Co., Ltd. is a professional designer of material handling equpment to meet the specific requirements of each client.Our product includes Industrial Trailers, Transfer Cars, Electric Railway Transfer Trolley, Scissor Lift Tables, Turntables and many other specialty items.Our special solution to the design of each product includes a detailed review of the client requirements, which is used to develop the Functional Specification of the product.Working closely with you, we will incorporate our years of design experience into the final design of the product to assure complete customer satisfaction.

Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material

Q/A

What Product Handling Applications Use Transfer Carts?
1. Coils (V-Groove deck)
2. Tanks (size/stability for uniformly distributed loads)
3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
4. Sub-Assembly shuttle from one line to another line
5. Maintenance cart for motors and pumps
6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
7. Material shuttle for steel tubing (flat decking with guard rails)
8. Elevating platform for assembly process (integrated screw-jack table)
9. Sand casting (flat decking)

How are the transfer trolley powered?
Powered AC carts have power cable connected directly to an electrical panel, typically for carts that travel along a fixed path. Cable reels can be installed for cable management.
Powered DC carts have on-board batteries that have an average running time of 16 hours. DC battery charging units can be installed on-board for convenience. Extended battery life can be accomplished by having four batteries rather than two.
How fast can the transfer trolley travel?
Typically, transfer carts come with drive motor speed of 50 fpm (with brake). Optional consideration can be given to ordering VFD (electric car only) for soft start/stop movement. Faster travel speeds can be ordered.
How to protect the transfer trolley as the temperature of scrap bucket or ladle is so high?
The materials, driving system and electrical control of the car would be specially designed. The heat insulating material is used in the car to resist the high temperature.
